In the power and electrical industries, Al-Mg-Si aluminum alloys are widely used, but the electrical conductivity of the material is relatively high.
6101 Aluminum bus conductor is often used to process high-strength busbar conductors. After aging treatment, its high-magnification metallographic structure, surface quality, hardness, electrical conductivity and mechanical properties can meet relevant requirements, and its electrical conductivity is greater than 55% IACS, tensile strength It can reach 172~221MPa, and the yield strength can also reach 138~186MPa.
The chemical composition of 6101 Aluminum bus conductor
Al (concentration): margin
Silicon: 0.30~0.7
Iron: ≤0.50
Copper: ≤0.10
Manganese: ≤0.03
Magnesium: 0.35~0.8
Chromium: ≤0.03
Zinc: ≤0.10
B: ≤0.06
titanium:-
Other elements not specified: each: ≤0.03; total: ≤0.10
Application of 6101 Aluminum bus conductor
6101 Aluminum bus conductor has high hardness and conductivity, and is often used to process high-strength busbar conductors.
