Introduction of 6061 Aluminum Seamless Bus Pipe
6061 Aluminum Seamless Bus Pipe adopts a series of advanced technologies such as domestic advanced hot-top casting seamless pipe, with smooth surface, high dimensional accuracy, high tensile strength, and is not easy to produce discharge and deformation;
Chemical composition of 6061 Aluminum Seamless Bus Pipe
Cu: 0.15~0.4
Mn:0.15
Mg:0.8~1.2
Zn:0.25
Cr:0.04~0.35
Ti:0.15
Si: 0.4~0.8
Fe :≤0.7
Al : margin
Features of 6061 Aluminum Seamless Bus Pipe:
1) It has excellent processing, welding, electrical conductivity and heat resistance properties.
2) Good convection heat dissipation conditions, low temperature rise, low loss, strong electrical conductivity and large current carrying capacity
3) The installation area is small, and the combined pipe bus is 1/3 of the area of the flexible conductor;
4) Corrosion resistance, not easy to be covered with ice, strong disaster resistance, long service life
